Secure the ThOR-HD to your Picatinny Rail using the Quick Release Mount as shown above. Remove the cap from the objective lens and rotate the focus adjustment ring, as necessary, to achieve the proper focus at various distances. You should not have to re-adjust the Diopter Adjustment unless another user, with different vision needs, uses the scope. Do not take the rubber cap off the objective lens. Look through the eyepiece, focusing on the reticle on the screen, and rotate the Diopter Adjustment Ring until optimal sharpness is achieved. Using LEFT or RIGHT buttons in the Menu will allow you to quickly choose Exit Shortcut from any position. Press and Hold - designed to be used in the following situations - ON/OFF, ZOOM and SHORTCUT MENU.Short and Quick Taps - used for most functions and to get around the menu.The KEYPAD is programmed to be used in two different ways:
#ATN 2000 FIRMWARE HOW TO#
Please refer to page 26 to learn how to perform the NUC process correctly. To TURN OFF the device, press and hold the POWER Button until the “Shut down the device?” appears in the dialog box. To TURN ON the device, press and hold the POWER Button until you see the ATN splash screen.
#ATN 2000 FIRMWARE UPDATE#
In the event you do not perform the previous actions, the system will ask you if you wish to update the device every time you turn it on. Once the device has been updated you will need to either format the card or delete the update file manually. If the device does not restart within 30 seconds, remove and re-insert the batteries, and again power-up the device.
Please remember to delete the Firmware File off of the microSD card after all steps are completed. Once the Firmware update completes, please do a factory reset before using the product. Motion Sensing platform will be configured when first turned on. After completing it will automatically restart and will be ready for use. Once the device is powered up it will enter self configuration mode. When the update counter reaches “100%” the device will automatically restart. In the “Firmware Update” dialog box select “Yes” to start the update. #ATN 2000 FIRMWARE DOWNLOAD#
Download the ***.bin file from (You may need to create an account, if you didn’t create it earlier) and copy to your microSD Card - root directory. DO NOT USE an additional source of power during firmware update! It will need to be sent back to the ATN factory for service. The device may crash, corrupting its system files. In the event of a power failure during an update. To update the new firmware you will need a microSD card and batteries that are fully charged. To receive a notification of new firmware updates, please register your device on our website (you’ll receive an email letting you know when the new firmware becomes available). If you are going to record video the microSD Card should be a Class 10 (10 Mb/sec) or faster and have capacity from 4 to 64 Gb.īefore operating your device, update the firmware to the latest version. When it pops up a few millimeters, it can be pulled with your fingers or tweezers. To remove the microSD Card from the slot, push it in using the same thin object. If you are going to record video, the microSD Card should be a Class 10 (10 Mb/s) or faster and have capacity from 4 to 64 Gb. When it pops up a few millimeters, it can be pulled with your fingers or tweezers. Make sure the device is turned off before inserting the microSD card into the slot. The device is equipped with microSD, micro USB and micro HDMI ports and can be found under the cap near the battery block (marked with appropriate icons on the cap).
Make sure that the device is turned off before changing source of energy (batteries or USB in power supply mode). You want to ensure you can unscrew the cap next time you replace batteries. Make sure that the Red O-Ring is not visible to prevent shut off issues due to recoil, but also Do not over-tighten! Return the battery cap into the housing socket (screw clockwise until finger tight).
Remove the battery cap by unscrewing it counter clockwise. They will provide much longer battery life. We highly recommend using lithium AA batteries. The ThOR-HD will operate on four AA-type Lithium batteries. If any accessories are missing or broken contact ATN’s Customer Service. Ensure that all optical surfaces are clean and ready for use. Inspect the device for damage to optical surfaces, body, eyecups, operation buttons, etc. Battery Lifetime Information and Power Kit Card. Open packaging box, remove ThOR-HD and check the contents.
The following steps must be performed prior to use: Download this manual (.PDF, 2.51 Mb) Unpacking
